Smart façades for sustainable buildings

With a low ceiling canopy and narrow profile, for excellent design © GEZE GmbH

The most beautiful way to say welcome © GEZE GmbH

The Revo.PRIME revolving door system impresses with its minimal canopy height. Thanks to the narrowest profile systems, it also impresses with maximum design in the entrance area - for more free space, more transparency and significantly more lightness.

Advantages of the Revo.PRIME automatic revolving door system:

• Very quiet running, low-wear drive solution with a canopy height of only 75 mm
• Precise closing of the door leaves with the side walls
• Effective insulation effect against draughts, weather and noise
• Adjustable automatic speed setting, in line with the number of people passing through
• Manual operation of the door possible, e.g. to carry out cleaning work

Natural ventilation with automated windows ensures efficient air exchange © GEZE GmbH

The new F 1200+ drive allows for large windows to be comfortably opened and locked in a manner that is easier, faster and safer to operate. The F 1200+ has a very powerful motor which can turn and tilt even heavy window elements of up to 200 kg of leaf weight and is extraordinarily quiet when doing so.

Advantages of the F 1200+ window drive:

• 3-in-1 function: Opening, locking and operating function combined in one drive
• Powerful motor for elements up to 3.5 m and 200 kg
• Intuitive to operate even for untrained users (for example in office and administrative buildings, hotels and educational institutes) thanks to user feedback
• Capacitive operating unit with integrated proximity sensor makes it easy and safe to use

The Slimchain chain drive convinces with its slim design. © GEZE GmbH

The Slimchain chain drive blends subtly into the façade with its slim, compact design. It also offers numerous applications:

Inward and outward opening windows with bottom-hung, top-hung and side-hung leaves are possible, as are top-hung outwardly projecting windows and parallel-opening vent windows. It can also be used in fresh air and exhaust air systems, smoke and heat extraction systems and in intelligent façades. There's nothing standing in the way of comfortable, natural ventilation: in schools, offices or gyms, or in your own four walls.

Advantages of the Slimchain 24 V window drive:

• Can be integrated perfectly into the façade design thanks to its slim and discreet look
• Individually adjustable drive stroke and speeds for ventilation and smoke & heat extraction
• Available as special version: Stroke, cable length, colour and alignment configurable to DIN left-hand/right-hand door
• Synchronisation of up to four drives without external control unit
• DIP switches for changing the mode of operation (Solo and Syncro, master, slave)
• Quick and easy to install thanks to the GEZE Smart Fix installation system
• IQ windowdrive for intelligent drive control
• Compatible with IQ box KNX and IQ box Safety interface modules
• Certified as a natural smoke and heat extraction system in accordance with EN 12101-2

TÜV-tested solution for maximum safety: IQ box Safety © GEZE GmbH

IQ box Safety is a new product in the field of window technology. Certified by TÜV (a German technical service organisation), IQ box Safety offers the highest level of safety for power-operated windows up to protection class 4. IQ box Safety is suitable for protecting closing edges on automatic windows with IQ windowdrive 24 V drives and enables switching strips and contactless sensors to be connected. Each window connects one IQ box Safety to up to four window drives and two locking drives. It is suitable for natural ventilation and smoke & heat extraction systems, as well as for all activations (such as control panels for smoke & heat extraction systems, 24 V power supplies, KNX, IQ gear). This therefore allows planners and architects greater flexibility and creative freedom in the layout of ventilation windows and smoke & heat extraction windows.

Advantages of IQ box Safety:

• Fulfils the requirements of the highest protection class in accordance with risk assessment for power-operated windows under the Machinery Directive (Protection class 4)
• TÜV certified functional safety in accordance with DIN EN 13849-1
• Four sensor connections that can be assigned to switch strips or non-contact sensors
• Top hat rail housing with pluggable terminals for quick and simple wiring
• Integrated push button for manually closing windows during servicing
• Top hat rail module with pluggable terminals for quick and simple wiring
• Parameters can be adjusted using GEZE service terminal ST 220

Tip: Learn more about this topic in our specialist talk “Healthy room climate – efficient exchange of air through natural ventilation”.

REGISTER NOW

Chain drive for large and heavy window elements that require large opening widths. © GEZE GmbH

The GEZE Powerchain electric Chain drive is suitable when large forces and very large opening widths are required. Nevertheless, it is quickly installed with the innovative GEZE Smart fix mounting system. With the commissioning case, the window drives from the IQ windowdrives series can be quickly and easily commissioned and tested even without a power connection.

Advantages of Powerchain:

• Fast opening speeds in the event of smoke and heat extraction, even for very heavy windows
• Continuously adjustable drive stroke and individual speeds for ventilation and smoke and heat extraction
• Available as special version - stroke, cable length and colour configurable
• Synchronisation of max. four drives without external control unit

Overhead door closer with guide rail for single leaf doors up to 1400 mm leaf width with latching action and brake-to-stop function © Getty Images / iStockphoto

A new generation of the TS 5000: Depending on requirements, a latching action can be set on the overhead door closer or the door leaf can be slowed down to the last opening degrees. The door is nevertheless pulled securely into the lock with constant force - even in difficult ambient conditions.

Advantages of TS 5000 SoftClose:

• Closing force of EN2-6 with variable adjustment
• Can be used for right and left hand doors without conversion
• Latching action / smooth latching function can be adjusted from the front via valve
• Closing speed can be individually adjusted

Door dampers on both sides for interior wooden hinged doors. © GEZE GmbH

Don't miss the new surface-mounted variant of the GEZE ActiveStop door damping system as well as the live installation demo at our trade fair stand. The system ensures the controlled, damped opening and closing of room doors and thus a whole new level of door comfort. The surface-mounted version is easy to stick on and can be removed again with virtually no residue. Also a real enrichment for retrofitting or for rented flats!

Advantages of GEZE ActiveStop:

• Door opening angle with variable adjustment from 80°-140°
• Can be used for right and left hand doors without conversion
• Soft opening and closing of doors up to max. 45 kg leaf weight
• Gentle stopping, quiet closing and comfortable keeping open of doors

Manual sliding wall systems (MSW) open, divide and separate rooms and adapt them to the respective use. © Sigrid Rauchdobler / GEZE GmbH

Manual sliding wall systems (MSW) stand for design freedom, safety and comfort. In restaurants, hotels, shopping malls or airports, they can be pushed together quickly and easily and at the same time are very easy to move. Discover many more advantages of the new MSW Comfort directly at our stand.

ICONIC AWARD 2020 Forr the MSW Comfort

Slim design with integrated fitting technology © GEZE GmbH

The compact GEZE Levolan sliding door system is the sophisticated solution for creating functional and effortlessly moving manual sliding doors for internal applications. New system components now facilitate assembly and adjustability of the entire sliding fitting system. Come to our stand and let us discuss your design requirements.

More about room partitioning

© GEZE GmbH

The new RSZ 7 smoke switch control unit with height-adjustable telescopic function ensures easy positioning of smoke inlets in difficult fall situations, e.g. if the ceiling is too low. Test the RSZ 7 directly at our stand in combination with a radio hold-open system and the TS 5000 SoftClose.

Advantages of RSZ 7:

• Telescopic function for bridging overhangs of up to 30 mm
• Connection to 230 V power supply and 24 V DC supply of the hold-open device
• Voltage supply of the hold-open system is interrupted in the case of an alarm and the doors close

Staircase control panel in robust metal housing with illuminated SHEV and ventilation buttons. © GEZE GmbH

The THZ N4 and THZ Comfort N4 Staircase control panel have been completely revised: They now have a more powerful power supply unit, which can be used to supply an additional window drive. In addition, both models are now equipped with an interface for the GEZE ST220 service terminal, with which commissioning and maintenance can be carried out more quickly and conveniently. A new connection terminal simplifies the connection of the motor line. Thanks to their small dimensions, the optimised THZ N4 and THZ Comfort N4 can also be installed inconspicuously in narrow stairwells.

Advantages of THZ N4 + THZ Comfort:

• Compact and attractive design with a very robust metal housing
• Increased safety due to integrated, illuminated RWA and ventilation button
• Adjustable backlight of the SHEV button
• Safety and reliability confirmed by VdS recognition and TÜV test

© Jürgen Pollak / GEZE GmbH

SHEV control units open window drives safely and reliably in case of fire and provide fresh air through controlled natural ventilation in everyday life. The new N8 version of the MBZ 300 modular bus control centre is impressive with its particularly compact housing. The right choice for small and medium-sized buildings as well as staircases: The MBZ 300 N8 can be individually configured and expanded thanks to its modular design. Standard functions can be configured by the number and sequence of modules.

Advantages of MBZ 300 N8:

• Modular design to allow flexible adaptation to project-specific requirements
• Convenient extension by clicking on another module in a control unit
• Simple service and installation thanks to status display directly on the module

Find out how easy it is to install the FA GC 170 in our video.

The GEZE wireless extension FA GC 170 connects ceiling detectors and manual release buttons wirelessly with the fall detector of GEZE hold-open systems. There is no need for separate cable routing. This simplifies planning, especially in listed buildings and when retrofitting hold-open systems in existing buildings. The system is tested according to the European standard for fire alarm systems DIN EN 54-25.

Advantages of FA GC 170 wireless extension kit:

• No cable connection needed between lintel-mounted detector and ceiling-mounted detector or manual trigger switch
• Simple coupling of the wireless components
• Mixed installation (wireless/wired) possible
• Low servicing costs due to long battery life of eight years

© GEZE GmbH

Accessibility, fire protection, safety – the legal requirements for building have increased enormously. For public buildings and especially for workplaces, health protection - here defined in the technical rules for occupational safety - is an additional important legal regulation. The aim of all these standards is to design buildings in such a way that they can be used by everyone without outside help and without restriction. We are presenting a simulated RDA safety staircase at our trade fair stand where you can test our GEZE Powerturn F/R and TS 5000 ECline under normal and alarm conditions.
